Forklift Drive Axle

Forklift Drive Axle - A forklift drive axle is a piece of machinery that is elastically connected to a vehicle frame with a lift mast. The lift mast is fixed to the drive axle and is capable of being inclined around the drive axle's axial centerline. This is done by at least one tilting cylinder. Frontward bearing parts along with rear bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing components. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H40, H45 and H35 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle framework itself. The drive axle is elastically affixed to the frame of the lift truck utilizing numerous various bearings. The drive axle consists of tubular axle body together with extension arms affixed to it and extend rearwards. This particular kind of drive axle is elastically connected to the vehicle framework utilizing back bearing elements on the extension arms along with forward bearing tools located on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the vehicle from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle are maintained through the back bearing components on the framework by the extension arms. The lift mast and the load create the forces which are transmitted into the road or floor by the frame of the vehicle through the drive axle's front bearing parts. It is important to make sure the elements of the drive axle are installed in a firm enough way to be able to maintain stability of the lift truck truck. The bearing parts can minimize minor bumps or road surface irregularities throughout travel to a limited extent and provide a bit smoother function.
